About us
Anytek LLC was founded in 2010 y a team of young development engineers. At that time, one of the main activities of the company was the development, production and sale of vending machines, such as snack vending machines, coffee machines and condoms. Condoms of the SELLER trade series, which were developed by our team were and continue remain the best of functionality and design on the Ukrainian market
A universal hardware and software vending platform was also created, using which it was possible to upgrade old coffee machines and give them a "second life". However, the vending direction of development at that time was not the only direction of the company's development. Another main activity of the company was contract development and custom production of electronic equipment.
Our team implements solutions in different fields of technology:
-
АТМ;
-
CPA;
-
industrial equipment;
-
equipment for housing and communal services;
-
vending equipment;
-
special-purpose equipment.
Time passes, everything changes in our world... At this stage, the company is focused on the development of solutions for interference-proof radio communication and related video data processing – transmission and reception of a video stream from various signal sources, data compression, digital image stabilization and recognition.
Projects
Accelarator of calculations
The device is made in a 4U form factor for integration into a standard server rack. The device provides active cooling due to built-in high-performance coolers. 10G Ethernet and 2x1G Ethernet interfaces are displayed on the front panel of the case for external connection.
- Arria 10 FPGA + MAX 10 FPGA
- 2xSODIMM DDR4 Memory
- 10G Ethernet
- 2x1G Ethernet
- 2xSerial Lite
- JTAG
- Power 12V/10А
Dispatch communication system
A complete hardware and software development of supervisory control and controller control for the x86 platform has been implemented.
- Cortex-M3 MCU
- 3 x Audio Channels (External PU)
- 2 x Relay Power Channel (Dry Output)
- 4 x External Digital Inputs
- RS485
- GSM/GPRS Modem (External Antenna)
- SIM-Card.
Fuel Level Remote Monitoring System for a fuel truck
A complete hardware and software development has been implemented to monitor the fuel level of the fuel truck. The software development included a web interface for the fuel level control application.
- Cortex-M3 MCU
- RS485
- GSM/GPRS Modem (External Antenna)
- SIM-Card.
We have also performed:
-
Various control controllers of vending machines;
- Industrial Equipment Controllers;
- A variety of temperature controllers;
- Test equipment for inspecting and testing devices in production;
-
Digital 3D printer control controller based on Zynq 7020;
- Digital controller based on Cyclone V;
-
Various solutions with Nvidia SoM (Jetson Nano, TX1/TX2, Xavier AGX);;
- Video capture controllers for analog and digital video;
- Various solutions with SerDes FPD-Link III;
- A variety of solutions for ATMs - thermal printers, specialized controllers for ATMs.
Modules for drones
Secure video conferencing system
Camcorder
The system uses a video camera with excellent characteristics and capabilities for digital image stabilization:
-
Sensor with high sensitivity in the IR range.
-
4М resolution.
-
30x optical (36x total) zoom on compact lenses to reduce weight and bulk.
-
Glare reduction thanks to a new aperture.
-
The function of obtaining a color image in the dark.
-
Improved autofocus with IR correction and additional autofocus algorithms.
-
Wide-D mode, which splits the image into multiple blocks to correct shadows and fades according to the difference in intensity.
-
Foggy view. If there is fog around the subject and low contrast, Fog Reduction Mode will reduce the effects of fog and make the subject clearer.
-
Visibility enhancer.
-
The Freeze function, which allows you to get a constant image.
Processor Module
Performs reception and processing of video data, as well as forms a package for radio broadcasting and control of radio modules.
The module is made on a specialized SoC, which has a separate dedicated hardware resource for recognizing and tracking objects. The recognition training procedure allows you to distinguish individual groups of objects and specific objects of the group. The effectiveness of recognition can be estimated in advance on the basis of a user-created model, which allows the improvement of such a model to the highest possible level.
The SoC has an H.264 hardware compressor that quickly performs 1x 1080P60 or 3x 1080p30 compression. An important feature of the codec is the dynamic adjustment of the bitrate, which is necessary to adapt the video stream to the existing quality and bandwidth of the radio channel (RSSI, SNR).
The built-in 4-channel Ethernet switch allows you to connect several radio modules at the same time and thus significantly expand the data transmission band.
Performs the functions of controlling radio modules. It can also perform the function of a flight controller, or have a connection with an existing one.
It has the ability to connect a video stream via FPD-Link III, USB 3.0, MIPI-CSI interfaces
Stabilization platform
A platform for stabilizing the "head" of the aircraft. It is made according to a simplified scheme in order to meet the weight and size requirements and have a low cost. The effect of image stabilization is achieved together with the digital image stabilization of the camcorder.
Camera-Processor Module Communication Interface Board
The board converts standard HDMI or MIPI-CSI digital interfaces to FPD-Link III, which makes it possible to transmit large (up to 4 Gbit/s) video streams and camera control commands over one thin coaxial cable. This significantly improves the location of equipment in the aircraft and reduces the weight of communication cables. Additionally, there is an option to transfer power.
Multi-Band Radio Module
A high-bandwidth radio module (up to 21 Mbit/s) operating in a wide frequency range from 1625 MHz to 2500 MHz, or from 3200 to 5200 MHz. They can be used both separately and together, taking into account the capabilities of the processor module, thus forming a fairly wide range of video data transmission. Together with the processor module and multi-band antennas, they form a system that relies on the invisibility of radio broadcasting and the dynamic avoidance of electronic warfare without losing the video stream.
The modules have the ability to act as a repeater and build a Mesh network. This allows you to increase the range without the need to amplify the signal and create conditions for radio visibility.
Structurally, modules are divided into 2 types. For an aircraft — it has a small size and weight and passive cooling, can be connected to video cameras of the SIYI ZR10 type without the use of a processor module. For the base station, it has active cooling and the ability to directly connect to Wi-Fi bridges to ensure the operator's distance from the BS within 1 km. It is also possible to directly connect satellite systems such as Starlink to the equipment.
Multi-Band Antenna
Directional antennas for installation on aircraft, in which a compromise is found between mass and size indicators, uniformity of VSC in operating ranges and passive gain. Made in two versions:
- Sectoral type:
- It consists of 2 antennas that form the working sector in the rear hemisphere of the quadcopter-type drone.
- Circular type:
- It consists of 6 antennas, as well as control and switching boards for working sectors. More suitable for drones with a glider.
